Future-proof alarm signalling in Europe
The IRIS* terminal provides a simple, reliable and proven way to convert existing analogue security installations to modern digital IP communication.
It has become one of the most widely used security systems in Europe, popular with security installers, control rooms and end users.
Now, with support for 4G and a new processor enabling double capacity and speed, these are enhancements that make the IRIS-4 terminal family future-proof for changes in mobile networks and new technologies.
All IRIS-4 products are tested and certified by the renowned VdS laboratories, according to the latest and highest European standards for alarm transmission.
*Please be advised that the IRIS product range is currently only available for purchase outside of the UK.
De IRIS 4-serie
Specifications AddSecure IRIS-4 series
| FEATURE | 160 | 200 | 220 | 240 | 400 | 420 | 440 | 620 | 640 |
|---|---|---|---|---|---|---|---|---|---|
| Fire retardant enclosure | - | - | - | - | - | ||||
| Battery backup | >15h | - | - | - | - | - | - | - | - |
| Touchscreen | - | - | - | ||||||
| Ethernet ports | 1 | - | 1 | 1 | - | 2 | 2 | 1 | 1 |
| WiFi | - | - | - | - | - | - | - | - | |
| 2/3/4G | - | - | - | ||||||
| Dial Capture | - | - | |||||||
| Relays | 3 | 3 | 3 | 3 | 4 | 4 | 4 | 4 | 4 |
| Inputs | 4 | 4 | 4 | 4 | 4 standard +12 with board add-on expansion | 4 standard +12 with board add-on expansion | 4 standard +12 with board add-on expansion | 6 | 6 |
| Serial RS485 | |||||||||
| Serial TTL | |||||||||
| RS232 (basic) | 1x full of 2x basics | 1x full of 2x basics | 1x full of 2x basics | 2x basics | 2x basics | ||||
| SMS Text messaging | - | - | - | ||||||
| Multi language menu | |||||||||
| VoIP- & SIP-services | |||||||||
| CAN bus | - | - | - | - | - | - | |||
| EN54-21 CPR Fire approved | - | - | - | - | - | - |
| Certifications |
|---|
| EN 50131, EN 50136 VdS Certificato) I terminali sono conformi ai requisiti delle norme europee: EN 50131-1: 2006+A2:2017 & EN 50131-10:2014 EN 50136-1: 2012 & EN 50136-2: 2013 Environmental Class II |
